Application

The SFE storage feeder ensures the right tension when knitting fabrics with intermittent yarn consumption, no matter what type of yarn is used. The speed of the DC motor is controlled by a micro-processor. Sensors monitor the size of the yarn reserve on the spool body and keep it constant.

Main features

- Even knit structure due to uniform yarn tension
- No fabric press-offs when the yarn breaks due to the inlet yarn sensor and yarn reserve on the spool body
- No over-storing of yarn windings, no loop formation

1. Winding reel

This has the smallest yarn store possible and ensures the optimum feed of individual yarn layers.

2. Sensor (fibre optic module)

The fibre optic sensor and the SFE microprocessor monitor the yarn store on the winding reel and regulate the motor speed to match yarn consumption.

3. Tensioner ring

Yarn tension is adjusted by using one of tensioner rings available.

4. Vibrating yarn tensioner

The vibrating yarn tensioner has magnetic tensioner rings to ensure that yarn tension remains constant. The continuous rotary motion of the tensioner ring keeps it clean. This prevent fault stoppages.

5. Outfeed stop (optional)

A built-in outfeed stop for the SFE is also available.

Technical data

Power supply	3 x 42 V +/- 10%, 50/60 Hz
Max. current / phase	1.41 A
Average current / phase	0.75 A
Max. power	100 VA
Average power	55 VA
Max. yarn feed rate	500 m/min
Yarn gauge range	83 dtex - 2500 dtex (Nm 4 - Nm 120)
Weight	2.61 kg
