Application
The MPF L impresses with its self-cleaning tension rings on the yarn infeed tensioner and closed wear-free yarn feed wheel. Other features include the integrated anti-filamentation unit and accessible yarn outlet tension to approx. 1 cN.
Main features
- Ease of operation, maintenance-friendly, wear-free, and long service life
- Self-cleaning vibrating yarn tensioner prevents machine stoppages and boosts productivity
- Even tension force due to magnetic tension rings
MPF L: The components
1. Vibration tension
The tension rings vibrates against the yarn direction of feed. This prevents the build-up of dirt between the tension rings and ensures they are self-cleaning.
2. Closed winding reel
The closed, low-wear winding reel prevents filament to build up when processing filament yarns.
3. Built-in anti-filamentation unit
When processing filament yarns capillary filaments can collect on the winding reel and interfere with smooth yarn feed. The user can prevent this by selecting the high take-off position for fibre yarns and the low take-off position for filament yarns.
4. Infeed arm (optional)
This eliminates the obstruction as with the normal infeed bracket and so makes it quicker to change the drive belt on the MPF.
Technical data
Stop motion electric circuit with yarn break Rated voltage (machine stoppage)
|
12 V or 24 V
|
|---|---|
Rated current
|
60 mA or 50 mA
|
Min. yarn tension
|
1 cN
|
Weight depending on version
|
430 g to 660 g
|
Versions
* MPF LF
* MPF LC
